Herbert
Herbert Pectus Bar Set and Chest Wall Instruments
Model Pectus Bar Set / GW2ZXBT225M
Herbert Pectus Bar Set GW2ZXBT225M, 17 bar lengths, low-profile stabilizer and sizing templates, with dimensions, materials and article numbers for surgical procurement.
PRODUCT HIGHLIGHTS
Product highlights
17 Pectus Bar lengths
Catalogue bars span 203–406 mm, in Stainless Steel 316 LVM, with a listed 12.7 × 3 mm section, serrated ends and Ø5 mm holes at both ends.
Bar preparation and bending instruments
The catalogue lists short/long tunneling instruments, handle, lever and table-top benders, bending cylinders and a Pectus Box.
Templates are distinct from implants
Aluminium 1100 templates are for external surgical preparation and sizing only. Do not implant.
TECHNICAL SPECIFICATIONS
Technical specifications
| Specification | Details / value and unit |
|---|---|
| Instrument set | Pectus Bar Set | GW2ZXBT225M |
| Pectus Bar | Stainless Steel 316 LVM | 12.7 × length × 3 mm | 17 lengths: 203, 216, 229, 241, 254, 267, 279, 293, 305, 318, 330, 343, 356, 368, 381, 394, 406 mm |
| Low-profile stabilizer | GD253DMZ02 | 15 × 60 × 5.3 mm | Stainless Steel 316 LVM |
| Sizing templates | Aluminium 1100 | 12.7 × length × 1 mm | 178, 203, 229, 254, 279, 305, 330, 356, 381, 406, 432 mm | Do not implant |
| Short / long tunneling | GW2ZXBT225D: 20 × 451.3 × 81.6 mm | GW2ZXBT225E: 20 × 484.3 × 88.6 mm |
| Handle bender | GW2ZXBT225F | 118 × 205 × 29 mm | Stainless Steel SUS420 |
| Bending cylinders | GW2ZXBT225G: Ø9.7 × 19.5 mm | GW2ZXBT225H: Ø11.7 × 19.5 mm | GW2ZXBT225J: specification table Ø13.8 × 19.5 mm; image heading states 13.7 mm. Confirm before ordering. SUS420. |
| Lever / table-top bender | GW2ZXBT225K: 36 × 267.3 × 56.5 mm | GW2ZXBT225L: 80 × 410 × 340 mm |
| Pectus box | GW2ZXBT221 | 337 × 567 × 101 mm | Aluminium 5083 |
EQUIPMENT & ACCESSORIES
Equipment & accessories
- Catalogue instrument family
Short/long tunneling, handle bender, three cylinder sizes, lever bender, table-top bender and Pectus Box. Confirm supplied quantities and contents in the quotation.
- Bars / stabilizer / templates
Related catalogue products. Do not assume all sizes or implants are included in GW2ZXBT225M; specify the required articles separately.
ADDITIONAL INFORMATION
Additional information
Pectus Bar length and code
203 mm: GD253DMZ031 | 216 mm: GD253DMZ032 | 229 mm: GD253DMZ033 | 241 mm: GD253DMZ028 | 254 mm: GD253DMZ029 | 267 mm: GD253DMZ024 | 279 mm: GD253DMZ018 | 293 mm: GD253DMZ019 | 305 mm: GD253DMZ020 | 318 mm: GD253DMZ021 | 330 mm: GD253DMZ022 | 343 mm: GD253DMZ025 | 356 mm: GD253DMZ026 | 368 mm: GD253DMZ030 | 381 mm: GD253DMZ027 | 394 mm: GD253DMZ034 | 406 mm: GD253DMZ035
Template length and code
178 mm: GW2ZXBT2252 | 203 mm: GW2ZXBT2253 | 229 mm: GW2ZXBT2254 | 254 mm: GW2ZXBT2255 | 279 mm: GW2ZXBT2256 | 305 mm: GW2ZXBT2257 | 330 mm: GW2ZXBT2258 | 356 mm: GW2ZXBT2259 | 381 mm: GW2ZXBT225A | 406 mm: GW2ZXBT225B | 432 mm: GW2ZXBT225C
Information for a quotation
Provide article numbers, quantities, bar/template lengths and stabilizer requirements. Confirm bending-tool selection. Implant selection and sizing require surgeon assessment and the manufacturer instructions.
คำถามที่พบบ่อย / FAQ
Can a template replace an implant bar?
No. The manufacturer specifies external preparation and sizing only; templates must not be implanted.
Does GW2ZXBT225M include every bar size?
The catalogue does not confirm inclusion of every bar size. Specify required instruments, bars, stabilizers and templates in the quotation.
What is the size of cylinder 225J?
The image heading states 13.7 mm, while the specification table states Ø13.8 × 19.5 mm. Manufacturer confirmation is required before ordering.
